Lepu solid mesh eagleburgmann seals supplier high pressure

Brand Name:
Lepu
Place of Origin:
Guangzhou, China
Model Number:
M3N
Shaft size:
6-80mm
Avaiable material:
CARBON/SIC/TC/CERAMIC
Certification:
SGS,ISO,CE/UL/SGS/…
OEM/ODM Availability:
Yes
Package:
Carton box
Delivery Time:
1 day
Supply Ability:
100000set/month
MOQ:
1 set
Payment Terms:
L/C, T/T, Western Union, MoneyGram
Inquiry
Product Comparison
Burgmann Mechanical Seal, manufactured based on high-quality materials and advanced technology, has excellent quality and favorable price. It is a trustworthy product which receives recognition and support in the market.Compared with other products in the same category, LEPU SEAL's Burgmann Mechanical Seal has the following advantages.
  • Lepu solid mesh eagleburgmann seals supplier high pressure 11
    Lepu solid mesh eagleburgmann seals supplier high pressure 12
Application Scope
Mechanical seal produced by LEPU SEAL is applied to the following industries.LEPU SEAL always focuses on meeting customers' needs. We are dedicated to providing customers with comprehensive and quality solutions.
  • Lepu solid mesh eagleburgmann seals supplier high pressure 13
Company Advantages
1. The materials are the soul of Lepu eagleburgmann mechanical seal catalogue and well-selected from top grade suppliers. These materials perform well in the whole lifespan of the product.
2. The product is less likely affected by a high vibration environment. All its electrical parts and components are integrated to resist impacts.
3. Guangzhou Lepu Machinery CO., LTD is responsible for final quality testing result.


Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For


This mechanical seal is a standard seal for plain shafts, this m3n mechanical seal designed with rotating conical spring, and it is a single and unbalance seal, and it is a dependent on direction of rotation seal type

As a standard mechanical seal, burgmann m3n seal is widely used in many kinds of industry pumps, like water pumps, sewage pumps, submerged pumps, chemical pumps, and so on.



PRODUCT ADVANTAGE

bg



1
1
100% same design as a replacement for burgmann m3n mechanical seal
1
1
Different type material for seal face, matching clients running request
1
1
Top quality stainless steel SS304 for seal frame and spring
1
1
Left rotating or right rotating spring are all available in our factory



Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-1
Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-2
Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-3

Advantage introduction:competitive price+ fast delivery+top after-sale service

PRODUCT TECHNICAL SPECIFICATION

bg


Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-4
  • ◪  Universal application opportunities

  • ◪  Insensitive to low solids content

  • ◪  No damage of the shaft by set screws

  • ◪  Large choice of materials

  • ◪  Short installation lengths possible (G16)

  • ◪  Short installation lengths possible (G16)



PRODUCT TECHNICAL DRAWING

bg


Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-5



SHAFT SIZE LIST

bg


Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-6


Working Range:

Pressure: p1 = 10 bar (145 PSI)
Temperature:
t = -20 °C ... +140 °C (-4 °F ... +355 °F)
Sliding velocity: vg = 15 m/s (50 ft/s)
Axial movement: ±1.0 mm



PRODUCT APPLICATION

bg


◪  Chemical industry

◪  Pulp and paper industry

◪  Water and waste water technology

◪  Building services industry

◪  Food and beverage industry

◪  Sugar industry

◪  Low solids content media

◪  Water and sewage water pumps

◪  Submersible pumps

◪  Chemical standard pumps

◪  Eccentric screw pumps

◪  Cooling water pumps


Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-7
Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-8



DISPLAY DIAGRAM

bg


Guangzhou Lepu machinery CO., LTD becomes one of the leading mechanical seal supplier in south of china, we focus in designing and manufacturing mechanical seal for many kinds of famous brand pumps, our mechanical seal cover many kinds of industry like food, petrol chemical, paper making, sea ship, and so on.


Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-9


undefined
undefined
undefined
Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-13
undefined
Lepu-High Quality Conical Spring Burgmann Mechanical Seal M3n For-15





Company Features
1. Guangzhou Lepu Machinery CO., LTD is a modern enterprise with first-rate independent research and development on eagleburgmann seals products.
2. Guangzhou Lepu Machinery CO., LTD's key technologies make its burgmann seals products more efficient and competitive.
3. Lepu Machinery seeks common ground while reserving differences with our customers. Get more info! The Lepu plan is to become an internationally renowned Burgmann mechanical seal supplier. Get more info! We are a professional eagleburgmann mechanical seal catalogue supplier with a strong influence on our market. Get more info! Customer Service from Lepu Machinery will ensure that our customers get the best products through professional ideas. Get more info!
