john crane mechanical seal 2100 2102 2103 for multi water pump1

Brand Name:
Lepu
Place of Origin:
Guangzhou, China
Model Number:
TYPE 2100/2102/2103
Shaft size:
10-100mm
Avaiable material:
CARBON/SIC/TC/EPDM/VITON, SS304 or SS316
Certification:
SGS,ISO,CE/UL/SGS/…
OEM/ODM Availability:
Yes
Package:
Carton box
Delivery Time:
15-20 day
Supply Ability:
100000 set/MONTH
MOQ:
1 set
Payment Terms:
L/C, T/T, Western Union, MoneyGram
Inquiry
Company Advantages
1. The development of Lepu bellow type mechanical seal adopts advanced technologies. They include computer-aided design, CNC machining, and sensor control technology. Lepu seal is extreme corrosion resistance
2. The product can meet varied demands of our clients and is being used more and more widely in the global market. Lepu products cost less than that of the original
3. metal bellow mechanical seal can deeply convince the client of its merits. Lepu seal is durable even running in bad environment
4. Lepu strives forward to ensure the high quality of this product. During the operation, Lepu seals enjoy higher precision
5. Its quality is qualified to meet the requirements of certifications. Compact gland allows Lepu seal to be used in limited space


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102


Compact, unitized, single-spring elastomer bellows seal, that is what we calling John crane mechanical seal 2100/2102/2103, offers maximum durability and performance in many demanding applications.

There are 3 kinds of tail for john crane mechanical seal type 2100, the normal size tail is we call 2100, and middle longer tail is 2102, the longest tail mechanical seal is 2103, please choose the right size base when buying this 2100 john crane seal.

Lepu seal is a leading manufacturer of the john crane mechanical seal type 2, providing promised quality stamping seals to hundreds of clients.



PRODUCT ADVANTAGE

bg



1
1
Top quality stainless steel for the frame and spring
1
1
100% follow original john crane seal design
1
1
Strong ability fit for mass order quanity
1
1
Top quality rubber parts



Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-1
Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-2
Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-3
Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-4

Advantage introduction:competitive price+ fast delivery+top after-sale service

PRODUCT TECHNICAL SPECIFICATION

bg


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-5
  • ◪ Sealing Face: Carbon, SIC, TC, Ceramic

  • ◪ Secondary Sealing Combination: NBR, EPDM, VITON

  • ◪ Sealing Frame: stainless steel

  • ◪ Working Temperature:-20℃ --- 120℃

  • ◪ Working pressure: ≤ 1.4MPA

  • ◪ Linear Speed:≤ 15m/s

  • ◪ Technical drawing


Product feature

◪  Innovative bellows design is pressure-supported and will not crease or fold under high pressure.

◪  Non-clogging, single-coil spring keeps seal faces closed and properly tracking during all phases of operation.

◪  Positive drive through interlocking tangs will not slip or break free during upset conditions.

◪  Available in the widest array of material options, including high performance silicon carbides.



PRODUCT TECHNICAL DRAWING

bg


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-6


Specification and size :


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-7



PRODUCT APPLICATION

bg


Pumps, mixers, blenders, agitators, air compressors, blowers, fans and other rotary shaft equipment


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-8


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-9
Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-10



DISPLAY DIAGRAM

bg


Guangzhou Lepu machinery CO., LTD becomes one of the leading mechanical seal supplier in south of china, we focus in designing and manufacturing mechanical seal for many kinds of famous brand pumps, our mechanical seal cover many kinds of industry like food, petrol chemical, paper making, sea ship, and so on.


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-11


Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-12
undefined
undefined
Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-15
undefined
Lepu-High Quality Heavy Duty John Crane Mechanical Seal 2100 2102-17





Company Features
1. The company has a team of patient and adaptable customer service professionals. They have abundant experience in handling irate, doubtful and chatty customers. Besides, they are always willing to learn how to provide better customer service.
2. Guangzhou Lepu Machinery CO., LTD strictly considers the needs of customers in metal bellow mechanical seal production. Get more info!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
