    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical


    Burgmann mechanical seal MG1/MG12/MG13 is a famous elastomer bellows seal widely used in many kind of industry, like Process industry, Chemical industry, Pulp and paper industry, Water and waste water technology, Food and beverage industry, Sugar industry, and so on.

    The MG1 can also be used as a multiple seal in tandem or in a back-to-back arrangement. Installation proposals available upon request.

    And for different using, there several type of the rubber tail, a middle long tail is MG12 mechanical seal, and longest tail is MG13 type. Please choose the right type tail when buying this mechanical seal MG1 type.



    PRODUCT ADVANTAGE

    bg



    1
    1
    100% same replacement for burgmann MG1/MG12/MG13
    1
    1
    Different type Top quality material for seal face, matching clients running request
    1
    1
    Different type rubber for different working liquid
    1
    1
    Different color rubber is available according client’s request, like green, black, brown.



    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-1
    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-2
    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-3
    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-4

    Advantage introduction:competitive price+ fast delivery+top after-sale service

    PRODUCT TECHNICAL SPECIFICATION

    bg


    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-5
    • ◪  For plain shafts

    • ◪  Single and dual seal

    • ◪  Elastomer bellows rotating

    • ◪  Unbalanced

    • ◪  Independent of direction of rotation

    • ◪  No torsion on bellows



    PRODUCT TECHNICAL DRAWING

    bg


    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-6



    SHAFT SIZE LIST

    bg


    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-7


    Working Range:

    Pressure: p1 = 16 bar (230 PSI),
    vacuum ... 0.5 bar (7.25 PSI),
    up to 1 bar (14.5 PSI) with seat locking
    Temperature:
    t = -20 °C … +140 °C
    (-4 °F … +284 °F)
    Sliding velocity: vg = 10 m/s (33 ft/s)
    Admissible axial movement: ±2.0 mm



    PRODUCT APPLICATION

    bg


    ◪  Process industry

    ◪  Chemical industry

    ◪  Pulp and paper industry

    ◪  Water and waste water technology

    ◪  Food and beverage industry

    ◪  Sugar industry

    ◪  Chemical standard pumps

    ◪  Helical screw pumps

    ◪  Stock pumps

    ◪  Circulating pumps

    ◪  Submersible pumps

    ◪  Water and waste water pumps


    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-8
    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-9



    DISPLAY DIAGRAM

    bg


    Guangzhou Lepu machinery CO., LTD becomes one of the leading mechanical seal supplier in south of china, we focus in designing and manufacturing mechanical seal for many kinds of famous brand pumps, our mechanical seal cover many kinds of industry like food, petrol chemical, paper making, sea ship, and so on.


    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-10


    undefined
    undefined
    undefined
    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-14
    undefined
    Lepu-High Quality Unbelievable Price High Quality Burgmann Mechanical-16
